Commercial Gas/Oil-fired Hot Water Boiler-H6

H6 Series Commercial Hot Water Boiler: Advanced Low-Emission Heating Systems for Commercial Facilities​​

Engineered to meet the rigorous demands of hotels, educational campuses, and retail centers, the H6 Series Commercial Hot Water Boiler delivers industry-leading thermal efficiency up to 98 percent alongside ultra-low nitrogen oxide emissions. This solution directly addresses rising energy costs and tightening environmental regulations across North America and Europe.

​​Core Technology Breakdown​​

​​1. Full Premixed Flat Flame Combustion System​​
The H6 boiler’s combustion chamber utilizes precision gas-air mixing technology to achieve complete fuel burn cycles. Third-party verified performance data confirms:

• Nitrogen oxide emissions below 30 milligrams per cubic meter
• Carbon monoxide levels under 10 parts per million
• Continuous combustion efficiency between 95 to 98 percent

This technology enables compliance with California South Coast AQMD Rule 1146 and similar standards.

​​2. Ultraten Heat Exchange Technology​​
Featuring patent-pending winged tubes with turbulence-enhancing grooves, the H6’s heat exchanger provides:

• Heat transfer coefficients five times higher than smooth-tube designs
• Water-side pressure drop limited to 0.14 bar at maximum flow rates
• Tolerance for total dissolved solids up to 500 milligrams per liter

​​3. Modular Fleet Optimization​​
Up to 16 boilers can be networked through integrated controllers that:

• Automatically distribute thermal loads based on real-time demand
• Enable seasonal efficiency improvements up to 12 percent
• Provide remote performance monitoring via web-enabled dashboards

​​Commercial Application Case Studies​​

​​Case 1: University Campus Retrofit ​

• Replaced six 1970s-era steam boilers with eight H6-500kW modules
• Annual natural gas consumption reduced by 1.2 million cubic meters
• Achieved 34 percent reduction in heating costs across 18 academic buildings

​​Case 2: Luxury Hotel Chain Upgrade​

• Installed twelve H6-350kW units with cascade control systems
• Maintains 24/7 hot water supply for 450 guest rooms and spa facilities
• Cut annual maintenance hours by 60 percent through predictive diagnostics

​​Technical Specifications Overview​​

​​Meta Description​​
The H6 Series Commercial Hot Water Boiler provides 98% efficiency with under 30mg/m³ NOx emissions. Designed for hotels, schools, and retail centers – reduce energy costs by 35% while meeting strict environmental standards. Request technical specifications.
