Fangkuai θ7 series steam boiler solves the problems of load fluctuation and condensate recovery in the pharmaceutical industry, and reduces natural gas costs and maintenance costs.
1. Steam Demand in Pharmaceutical Processing
Pharmaceutical plants require steam that is ultra-clean, bone-dry and precisely controlled for critical processes such as autoclave sterilization, CIP (clean-in-place) cycles and aseptic filling. Autoclaves demand maintaining temperature within ±0.2 °C, even when feedwater conditions vary, to ensure complete microbial inactivation. In addition, clean-steam generators must deliver nearly 100% dry steam in order to prevent contamination of sensitive drug formulations.
2. Our Industrial Steam Boiler Solutions
Our Euromonitor 7 series oil/gas‑fired condensing steam boilers are engineered for continuous pharmaceutical operations. Key features include:
-
Ultra‑tight thermal control: ±0.2 °C stability from –10 °C to 150 °C feedwater to meet sterilization cycle requirements.
-
Corrosion‑resistant design: Special combustion chamber materials maintain 99.8% uptime in high‑humidity cleanrooms.
-
Intelligent diagnostics: Real‑time visualization of O₂/CO ratios and steam output optimizes efficiency for viscosity‑sensitive processes.
-
Regulatory compliance: Fully compliant with FDA 21 CFR and EU GMP Annex 15 standards, ensuring steam purity.
- Modular Design: Our industrial steam boiler uses an intelligent PLC control system to link multiple units in parallel. This not only boosts load‑adjustment flexibility but also strengthens overall operational resilience.
- Skid‑Mounted Steam Boiler: Each unit is fully pre‑assembled and factory‑tested inside a container. All internal piping and components are in place before shipment. On‑site installation is as simple as anchoring the skid and hooking up the feed‑water line, chimney, 350 V/50 Hz power supply, steam outlet piping and gas line—then it’s ready to fire up.
3. Condensate Recovery Solution for Pharma
To stabilize condensate return in fluctuating pharma loads, our system employs a three‑stage heat recapture circuit combined with an air preheater:
-
Air Preheating: Recovered condensate heat warms combustion air, boosting burner efficiency and minimizing thermal shock.
-
Stage‑wise Mixing: Dual‑pressure feed modulates up to 80% mixed condensate without efficiency loss, eliminating condensate “slug” impacts on steam quality.
-
Safety Interlocks: Automated isolation between return and makeup water prevents cross‑contamination and ensures compliance with hygienic standards.
4. Thermal‑Storage Load‑Bearing for High‑Frequency Variations
Pharma lines often cycle on/off rapidly during batch transitions, risking energy waste from boiler cycling. Our thermal‑storage solution:
-
High‑capacity accumulator: An enlarged hot‑water reservoir increases stored thermal mass when load drops, smoothing demand curves.
-
Automated balancing: PLC‑driven modulation shifts surplus heat into storage, then redeploys it instantly during spikes—avoiding frequent burner starts.
-
Energy savings: Reduces cycling losses by up to 15% and extends burner life by minimizing ignition cycles.
5. Boiler Product Parameters for the Pharmaceutical Industry
Actual parameters of steam boiler with production pressure of 1.2Mpa and temperature of 194℃:
Model | Evaporation (t/h) | Feedwater Temp (°C) | Thermal Efficiency | Gas consumption (Nm³/h) |
---|---|---|---|---|
θ7‑2000 | 2 | 150 (80%) 20 (20%) |
97 %–103.8 % | 136.02 |
θ7‑4000 | 4 | 150 (80%) 20 (20%) |
97 %–103.8 % | 272.04 |
θ7‑6000 | 6 | 150 (80%) 20 (20%) |
97 %–103.8 % | 408.05 |
θ7‑8000 | 8 | 150 (80%) 20 (20%) |
97 %–103.8 % | 544.07 |
θ7‑10000 | 10 | 150 (80%) 20 (20%) |
97 %–103.8 % | 680.1 |
θ7‑15000 | 15 | 150 (80%) 20 (20%) |
97 %–103.8 % | 1020.14 |
θ7‑20000 | 20 | 150 (80%) 20 (20%) |
97 %–103.8 % | 1360.18 |
θ7‑25000 | 25 | 150 (80%) 20 (20%) |
97 %–103.8 % | 1700.23 |
θ7‑30000 | 30 | 150 (80%) 20 (20%) |
97 %–103.8 % | 2040.27 |
FangKuai Euromonitor 7 Series delivers tailored steam boiler solutions that guarantee regulatory compliance, energy efficiency, and operational reliability—optimizing pharmaceutical production from sterilization to formulation.
