Gas Consumption of an 8 Ton Gas Steam Boiler per Hour

8t/h gas steam boiler, output steam temperature : 194℃, the gas consumption is about 500Nm³/h – 600Nm³/h. The higher the thermal efficiency, the more gas cost can be saved.

1. Boiler Specifications

• Rated Evaporation Capacity: 8 t/h (steam flow at full load)

• Rated Pressure: 1.25 MPa

• Saturated Steam Temperature: 194 °C

• Fuel: Natural gas (lower heating value, LHV): 9 140 kcal/Nm³

• Heat Efficiency:

  • Up to 103% LHV at 20 °C feedwater

  • Up to 97% LHV at 90 °C feedwater

• Maximum Achievable Efficiency: 107% LHV (with economizer and low-loss design)

Understand the detailed parameters of the boiler

2. Fundamental Calculation

Fuel consumption is derived from the energy balance between steam output and fuel input. In general:

Gas consumption (Nm³/h)=[ Steam enthalpy gain per hour (kcal/h) ] /  [ Gas LHV (kcal/Nm³)×Boiler efficiency ]​

• Steam enthalpy gain = Boiler evaporation capacity × Enthalpy of evaporation

• For saturated steam at 1.25 MPa (≈194 °C), the evaporation enthalpy (latent heat) is ∼ 539 kcal/kg.

• Thus, 8 000 kg/h × 539 kcal/kg ≈ 4 312 000 kcal/h.

Get a Steam Boiler Quote List

3. Consumption at Different Feedwater Temperatures

Note: The boiler’s efficiency varies with feedwater temperature because pre‐heated feedwater reduces the net heat required for evaporation.

4. Regional Variations in Fuel Cost

Natural‐gas calorific value and unit price differ by region. For cost estimation:

1. Determine Local Gas Price: (e.g., $0.30–0.60 per Nm³)

2. Calculate Hourly Fuel Cost:

   $$\text{Cost}=\text{Consumption (Nm³/h)}\times \text{Price (per Nm³)}$$

Example: At $0.45/Nm³ and 20 °C feedwater:

544 Nm³/h×$0.45/Nm³=$244.80/h

5. A-Level Steam Boilers Advantages

• High Efficiency: Up to 107 % LHV, minimizing gas usage.

• Economizer Integration: Recovers flue‐gas heat to boost preheating and reduce fuel.

• Customized Design: We offer free fuel‐cost calculations and complete boiler‐room design.

• Comprehensive Support: From installation to maintenance, ensuring optimal operation and safety.

Contact Now

Given the variability in natural‐gas quality and pricing across different locales, we invite you to reach out for a customized, no‐obligation fuel‐cost calculation and a boiler‐house layout proposal tailored to your project.
